Concrete Pump Snapshot
Boom Sections
Vertical Reach
Horizontal Reach
Max Output
General Specifications
Boom Specifications:
| Sections | 5 |
| Fold Type | ZR-Fold |
| Vertical Reach | 37.5M |
| Horizontal Reach | 33.6 M |
| Unfold Height | 7.1 M |
| Rotation | 370 Degrees |
| End Hose Length | 4 M |
| Delivery Line | DN125 |
Outrigger Specifications:
| Front Spread | 6.25 M |
| Rear Spread7.79 | M |
| Maximum Outrigger Weight | 21,800 KG |
Pump Specifications:
| Maximum Output | 170m3/ hr |
| Delivery Cylinder Diameter | 230mm |
| Stroke Length | 2100mm |
| Strokes per Minute | 32 |
| Concrete Pressure Rod Side | 72 Bar |
| Hopper Capacity | 600 LITRES |
Concord Concrete Pumps Australia reserves the right to modify specifications, designs and product range at any time.
Features:
Standard Features
- Rexroth Hydraulic Pumps
- LED Boom Lighting
- Water washout pump
- Pump manual overrides
- LED Pump Side Lighting
- 2 x Operating / Parts manuals
- Hopper Vibrator
- Air Blowout Tank, hoses & cap
- Magnetic Hopper Light
- Lincoln Auto Greaser hopper only
- Hardox Steel Pipeline
- Proportional Boom Control
- Concrete cylinders hard chromed
- Hopper fold down lid
- Low Unfold Height
- Proportional pump flow output
- Rubber flaps fitted under hopper
- 4 x Outrigger Pads
- Autec radio remote control
- Hopper Diesel Sprayer
- 2 x Outrigger Pad Holders
- Cable backup remote control 20M
- Spare hydraulic hose kit
- Toolbox with basic repair items
Optional Features:
- Twin Wall Pipeline
- HBC Radio Remote Control
- Air Shut Off Valve
- Pressure cleaner and retractable hose reel
Truck Options:
- FUSO
- HINO
- UD
- DAF
- ISUZU
- VOLVO
